Perkenalan
This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Extraflame Elisir Idro 12.7 kW Water-Bearing Pellet Stove. Please read this manual thoroughly before installation or use and retain it for future reference.
The Elisir Idro pellet stove is designed to provide efficient heating by burning wood pellets. It features electronic control for combustion, transferring heat primarily to water for central heating systems, with a small portion released into the installation room. The integrated pellet tank and transport auger ensure automatic fuel supply for extended periods. A programmable weekly timer and automatic ignition offer convenient, automated heating.
Informasi Keselamatan Penting
Always adhere to local regulations and safety standards during installation and operation. Improper installation, adjustment, alteration, service, or maintenance can cause injury or property damage. Consult a qualified installer, service agency, or the gas supplier for assistance.
- Pastikan ventilasi yang memadai di area pemasangan.
- Jangan menyimpan atau menggunakan bensin atau uap serta cairan mudah terbakar lainnya di dekat peralatan ini atau peralatan lainnya.
- Jauhkan anak-anak dan hewan peliharaan dari permukaan kompor yang panas.
- Hanya gunakan pelet kayu yang telah disetujui sebagai bahan bakar.
- Regularly inspect and clean the flue system.
Pengaturan dan Instalasi
The Elisir Idro pellet stove is designed for integration into existing heating systems, capable of supplying radiators and underfloor heating. Connection to domestic hot water systems is also possible.
Membongkar
Carefully remove the stove from its packaging. Inspect for any damage incurred during transit. Report any damage to your supplier immediately.
Penempatan
Position the stove on a non-combustible surface, ensuring sufficient clearance from combustible materials as specified in local building codes and the detailed installation manual (not included here, but implied). Ensure the floor can support the weight of the stove.
Koneksi Buang
Connect the stove to a suitable and properly sized flue system. All connections must be sealed to prevent smoke leakage. Consult a certified technician for flue system installation.
Koneksi Hidrolik
The stove features an integrated pump, a closed expansion vessel, and a built-in overpressure safety valve. Connect the stove's water outlets to your central heating system. Ensure all connections are watertight and pressure-tested according to plumbing standards.
Sambungan Listrik
Connect the stove to a grounded electrical outlet. Ensure the power supply matches the stove's requirements. The electronic control system manages fuel supply, smoke extraction, combustion air supply, and pump activation for optimal combustion efficiency.
Image: The Extraflame Elisir Idro pellet stove, bordeaux color, installed in a modern living room. The stove is connected to a flue system (not visible) and integrated into the home's heating infrastructure.
Petunjuk Pengoperasian
The Elisir Idro pellet stove offers automated operation through its electronic control system and programmable features.
Filling the Pellet Tank
Open the pellet tank lid and fill with high-quality wood pellets. Ensure no foreign objects enter the tank. The integrated transport auger will automatically feed pellets to the combustion chamber.
Panel Kontrol
The control panel allows you to monitor and adjust various performance parameters. These include fuel supply, smoke extraction, combustion air supply, and pump activation. Refer to the on-screen display for current settings and operational status.
Automatic Ignition and Timer
Utilize the programmable weekly timer to set desired operating schedules. The stove features automatic ignition, allowing it to start and stop according to your programmed settings, providing fully automatic heating.
Kontrol Jarak Jauh
An infrared remote control is included for convenient adjustment of settings from a distance. Point the remote control towards the stove's receiver.
Optional GSM Module
The Elisir Idro pellet stove can be optionally operated via a GSM module using a mobile phone. This module is sold separately and allows for remote control and monitoring functionalities.
Gambar: Detail view of the Extraflame Elisir Idro pellet stove, highlighting the front panel with its display and controls, and the glass window showing the burning pellets inside the combustion chamber.
Pemeliharaan
Regular maintenance ensures the longevity and efficient operation of your pellet stove. Always ensure the stove is cool and disconnected from the power supply before performing any maintenance.
Daily/Weekly Cleaning
- Penghapusan Abu: Empty the ash pan regularly. The frequency depends on usage and pellet quality.
- Ruang pembakaran: Clean the combustion chamber and burner pot to remove any unburnt residue.
- Pembersihan Kaca: Clean the ceramic glass door with a suitable glass cleaner designed for stoves when cool.
Monthly/Seasonal Cleaning
- Sistem Cerobong Asap: Inspect and clean the flue pipes and chimney. Blockages can reduce efficiency and pose a safety hazard.
- Penukar panas: Clean the heat exchanger surfaces to maintain optimal heat transfer efficiency.
- Pellet Hopper: Periodically inspect the pellet hopper for dust or foreign material.
Pelayanan Profesional
It is recommended to have your pellet stove professionally serviced at least once a year by a qualified technician. This includes checking all mechanical and electrical components, seals, and safety devices.
Penyelesaian Masalah
This section provides solutions to common issues you might encounter. For problems not listed here, or if solutions do not resolve the issue, contact qualified service personnel.
| Masalah | Kemungkinan Penyebab | Larutan |
|---|---|---|
| Kompor tidak menyala. | No pellets in hopper, igniter failure, blocked burner pot. | Check pellet level, clean burner pot, contact service for igniter. |
| Keluaran panas rendah. | Dirty heat exchanger, poor quality pellets, incorrect settings. | Clean heat exchanger, use recommended pellets, adjust power settings. |
| Asap berlebihan. | Blocked flue, insufficient combustion air, wet pellets. | Check and clean flue, ensure air intake is clear, use dry pellets. |
| Air tidak memanas. | Pump malfunction, air in system, low water pressure. | Check pump operation, bleed air from system, verify system pressure. |
Spesifikasi Teknis
- Merek: api ekstra
- Model: Elisir Idro
- Daya Total: 13.8 kW
- Daya Nominal: 12.7 kW
- Water-Side Power: 10.5 kW
- Air-Side Power: 2.2 kW
- Warna: Bordeaux
- ASIN: B00GO06YN2
- Tanggal Pertama Tersedia: 15 Januari 2020
- Fitur: Electronic control, integrated pellet tank, transport auger, programmable weekly timer, automatic ignition, integrated pump, closed expansion vessel, built-in overpressure safety valve, infrared remote control, optional GSM module compatibility.
Garansi dan Dukungan
For warranty information, please refer to the documentation provided with your purchase or contact your authorized Extraflame dealer. Keep your proof of purchase for warranty claims.
For technical support, service, or spare parts, please contact your local Extraflame service center or the retailer from whom you purchased the product. Always provide the model number (Elisir Idro) and ASIN (B00GO06YN2) when seeking support.
