BRISA VW Collection T1 Bus Bluetooth Speaker User Manual

Perkenalan

Terima kasih sudah membeliasing the BRISA VW Collection T1 Bus Bluetooth Speaker. This manual provides essential information for the safe and efficient use of your new portable speaker. Please read it thoroughly before use and retain it for future reference.

Image: The BRISA VW Collection T1 Bus Bluetooth Speaker in blue and white, showcasing its iconic design.

Pengaturan

Isi Paket

• BRISA VW Collection T1 Bus Bluetooth Speaker
• Kabel Pengisian Daya USB
• Panduan Pengguna

Pengisian Awal

Before first use, fully charge the speaker. Connect the provided USB charging cable to the USB-C charging port located at the rear of the speaker and to a compatible USB power source. The charging time is approximately 3 hours.

Gambar: Belakang view of the speaker, highlighting the USB-C charging port, 3.5mm AUX input, and the power button.

Daya Hidup/Mati

To power on the speaker, locate the power button at the rear of the Bus and press it. To power off, press the button again.

Operasi

Pairing Bluetooth

1. Pastikan speaker dihidupkan.
2. The speaker will automatically enter Bluetooth pairing mode, indicated by blinking LED headlights.
3. Pada perangkat seluler Anda (smartphone, tablet), aktifkan Bluetooth dan cari perangkat yang tersedia.
4. Select "VW T1 Bus Bluetooth Speaker" from the list of devices.
5. Once connected, the LED headlights will stop blinking and remain steadily lit.

The Bluetooth range is approximately 10 meters (30 feet). For optimal connection, keep your device within this range.

Gambar: Depan view of the speaker, showing the LED headlights which indicate pairing status.

AUX Audio Connection

For devices without Bluetooth, you can use the 3.5mm AUX audio jack located at the rear of the speaker. Connect an AUX cable (not included) from your audio source to the speaker's AUX input.

Daya Tahan Baterai

The speaker provides an operating time of up to 57 hours on a full charge, depending on usage volume and conditions.

Pemeliharaan

Petunjuk Perawatan

• Keep the speaker away from moisture and direct water exposure. It is not water-resistant.
• Hindari suhu ekstrem.
• Jangan menjatuhkan atau membenturkan speaker dengan keras.

Pembersihan

Bersihkan speaker dengan kain lembut dan kering. Jangan gunakan pembersih abrasif atau pelarut.

Penyelesaian Masalah

Tidak Ada Daya

• Pastikan speaker terisi penuh. Sambungkan ke sumber daya menggunakan kabel pengisi daya USB.
• Pastikan tombol daya ditekan dengan kuat.

Tidak Dapat Terhubung melalui Bluetooth

• Make sure the speaker is in pairing mode (blinking LED headlights).
• Pastikan Bluetooth diaktifkan di perangkat seluler Anda.
• Dekatkan perangkat Anda ke speaker (dalam jarak 10 meter).
• Turn off and on both the speaker and your device's Bluetooth, then try pairing again.
• Jika sebelumnya telah dipasangkan, coba lupakan perangkat di ponsel Anda dan pasangkan kembali.

Tidak Ada Suara

• Periksa tingkat volume pada speaker dan perangkat Anda yang terhubung.
• Ensure the speaker is properly paired via Bluetooth or connected via AUX cable.
• If using AUX, ensure the cable is fully inserted into both the speaker and the audio source.

Spesifikasi

Gambar: Samping view of the speaker, illustrating its dimensions: 19.5 cm (7.7 in) length, 8.5 cm (3.3 in) width, and 7.5 cm (3 in) height.

Garansi & Dukungan

Informasi Garansi

This product comes with a 6-month manufacturer guarantee. Please retain your proof of purchase for warranty claims. The warranty covers manufacturing defects but does not cover damage caused by misuse, accidents, or unauthorized modifications.

Dukungan Pelanggan

For further assistance or inquiries, please visit the official BRISA VW Collection weblokasi: vw-collection-by-brisa.com.
