Yoidesu BL02 Language Translator Earbuds User Manual

Perkenalan

This manual provides detailed instructions for the Yoidesu BL02 Language Translator Earbuds. Please read this manual carefully before using the device to ensure proper operation and to maximize its features. The BL02 earbuds offer real-time language translation, high-fidelity audio, and a comfortable design for various applications.

Produk Selesaiview

Image: The Yoidesu BL02 Language Translator Earbuds shown within their transparent charging case, with the lid open.

The Yoidesu BL02 are advanced language translator earbuds featuring Bluetooth 5.3 connectivity, support for over 144 languages, and intelligent noise reduction. They are designed for efficient communication and high-quality audio playback.

Image: A display of the BL02 Language Translator Earbuds and their charging cases available in White, Skin Color, and Black variants.

Pengaturan

1. Mengisi Daya Earbud dan Casing

Before first use, ensure both the earbuds and the charging case are fully charged. Place the earbuds into the charging case. Connect the charging case to a power source using a compatible USB cable.

Image: The BL02 charging case with text indicating 1.5 hours for fast charging, 48 hours of life with charging pods, and 90 days of standby time with the charging pod.

• Earbuds: Built-in 30mAh*2 Li-ion battery.
• Charging Compartment: Built-in 250mAh Li-ion battery.
• Fast Charging: Approximately 1.5 hours.
• Battery Life: Up to 48 hours with the charging case.
• Standby Time: Up to 90 days with the charging case.

2. Instalasi Aplikasi

To utilize the translation features, download the dedicated application. Refer to the QR code or link provided in the physical manual included with your product for the correct application download.

3. Pemasangan Bluetooth

Once the earbuds are charged:

1. Buka casing pengisi daya. Earbud akan otomatis masuk ke mode berpasangan.
2. Pada telepon pintar atau perangkat Anda, aktifkan Bluetooth.
3. Pencarian untuk "BL02" or a similar device name in the list of available Bluetooth devices.
4. Select "BL02" to connect. A voice prompt will confirm successful pairing.

Image: The BL02 earbuds next to a smartphone, illustrating Bluetooth V5.3 connectivity for high-speed and stable transmission with low latency.

The BL02 earbuds utilize Bluetooth 5.3 for a stable and high-performance connection, with latency as low as 50ms.

Petunjuk Pengoperasian

1. Language Translation Functionality

The BL02 supports over 144 languages for online translation. After pairing and opening the dedicated app:

1. Open the translation application on your connected device.
2. Select your native language and the target language within the app.
3. Choose one of the three translation modes:

Image: Diagram illustrating the three primary translation modes: Touch Mode, External Mode, and Free Talk Mode, with descriptions for each.

• Mode Sentuh: Designed for two individuals. Each person wears one earbud. Tap or double-tap the earbud to initiate real-time translation. This mode is suitable for conversations with acquaintances.
• Mode Eksternal: For situations where only one person wears an earbud. The earbud wearer speaks, and the translation is played through the connected smartphone's speaker. The other person speaks into the phone's microphone, and the translation is heard by the earbud wearer. This mode is suitable for interacting with strangers.
• Mode Bicara Bebas: Both individuals wear an earbud. This mode allows for continuous real-time translation without manual input, enabling hands-free conversation.

Image: Two individuals engaged in a conversation, with text bubbles demonstrating real-time translation between Chinese and English using the BL02 earbuds.

2. Multifunctional Touch Controls

The BL02 earbuds feature binaural fingerprint control, allowing you to manage various functions by touching the earbuds:

• Pemutaran Musik: Tap to play/pause, double-tap for next track, triple-tap for previous track (specific gestures may vary by app/device).
• Manajemen Panggilan: Ketuk untuk menjawab/mengakhiri panggilan, tekan lama untuk menolak panggilan.
• Asisten Suara: Long press to activate your device's voice assistant (e.g., Siri, Google Assistant).
• Translation Activation: Specific gestures within the translation app will activate translation in the chosen mode.

Image: A woman wearing a BL02 earbud, highlighting the multi-functional touch controls for music, calls, and other features.

3. Fitur Audio

The earbuds provide HiFi stereo sound with a graphene diaphragm and high-quality voice coil for professional triple-frequency tuning, enhancing listening experiences for music, calls, and games.

Gambar: Sebuah ledakan view of the BL02 earbud's internal components, highlighting the graphene diaphragm and high-quality voice coil responsible for its sound performance.

Pemeliharaan

• Pembersihan: Use a soft, dry, lint-free cloth to clean the earbuds and charging case. Avoid using abrasive materials or harsh chemicals.
• Penyimpanan: Saat tidak digunakan, simpan earbud di dalam wadah pengisi dayanya untuk melindungi dan menjaga dayanya tetap terisi. Simpan di tempat yang sejuk dan kering, jauhkan dari sinar matahari langsung dan suhu ekstrem.
• Pengisian daya: Always use the provided charging cable or a certified equivalent. Avoid overcharging for extended periods.
• Tahan Air: Earbud ini tidak tahan air. Hindari paparan air, hujan, atau kelembapan berlebihan.

Penyelesaian Masalah

Masalah Umum dan Solusinya:

• Earbud tidak dapat dipasangkan:
  • Pastikan earbud terisi daya.
  • Matikan dan nyalakan Bluetooth pada perangkat Anda.
  • Masukkan kembali earbud ke dalam wadah, tutup, lalu buka kembali untuk mengatur ulang mode pemasangan.
  • Forget "BL02" from your device's Bluetooth list and try pairing again.
• Tidak ada suara atau kualitas audio buruk:
  • Periksa volume perangkat dan volume earbud.
  • Pastikan earbud terpasang dengan benar di telinga Anda.
  • Bersihkan segala kotoran dari speaker earbud.
  • Sambungkan kembali earbud ke perangkat Anda.
• Translation not working or slow:
  • Pastikan perangkat Anda memiliki koneksi internet yang stabil.
  • Verify the correct source and target languages are selected in the app.
  • Check if the translation app requires updates.
  • Ensure the app's subscription for translation services is active (mentioned as "of for one year" in product features, implying a limited free period).
  • Bicaralah dengan jelas dan dengan kecepatan sedang.
• Earbud tidak mengisi daya:
  • Pastikan kabel pengisian daya tersambung dengan aman ke casing dan sumber daya.
  • Periksa apakah kasing pengisi daya memiliki daya.
  • Bersihkan kontak pengisian daya pada earbud dan casing.
  • Cobalah kabel pengisi daya atau adaptor daya yang lain.

Spesifikasi

Garansi dan Dukungan

Informasi Garansi

Specific warranty details for the Yoidesu BL02 Language Translator Earbuds are typically provided with the product packaging or can be obtained directly from the retailer or manufacturer at the time of purchase. Please retain your proof of purchase for warranty claims.

Dukungan Pelanggan

For further assistance, technical support, or inquiries regarding your Yoidesu BL02 earbuds, please contact Yoidesu customer service through their official websitus atau informasi kontak yang disediakan dalam dokumentasi produk Anda.
