Ohniyou 60" Industrial Ceiling Fan with Lights

1. Pendahuluan dan Selesaiview

The Ohniyou 60-inch Industrial Ceiling Fan with Lights is designed for both indoor and outdoor use, offering advanced control features and energy efficiency. It features a durable aluminum alloy construction, dimmable LED lighting with adjustable color temperatures, and a reversible DC motor for year-round comfort. The fan operates quietly and can be controlled via remote or a dedicated mobile application.

The Ohniyou 60-inch white ceiling fan, showcasing its sleek design and included remote control and mobile app interface.

Key features of the Ohniyou ceiling fan, highlighting its smart control options and versatile functionalities.

2. Informasi Keselamatan

Please read all instructions carefully before installation and use. Retain this manual for future reference. Always ensure the power supply is disconnected before performing any installation, maintenance, or troubleshooting. Installation should be performed by a qualified electrician. Ensure the mounting structure can support the fan's weight. Do not insert objects into the fan blades while in operation. Keep children and pets away from the fan during operation.

3. Isi Paket

Verify that all components are present and undamaged before beginning installation. If any parts are missing or damaged, please contact customer support.

Sebuah selesaiview of the components included in the Ohniyou ceiling fan package.

• Tubuh Motor
• Blades (6x)
• Metal Plate + Light Cover
• Blades Arms (6x)
• Mounting Bracket
• Batang penyangga (5 inci dan 10 inci)
• Kanopi
• Penutupan Sambungan
• Paket Keseimbangan
• Buku petunjuk
• Kontrol Jarak Jauh
• Penerima
• Installation Package (screws, etc.)

4. Pengaturan dan Instalasi

Ikuti langkah-langkah ini dengan cermat untuk pemasangan yang benar. Disarankan untuk melakukan pemasangan oleh dua orang.

4.1. Install the Fan Blade Edge Cover

1. Take out a fan blade and identify its first and last ends. The three holes are for connecting the motor later.
2. Install the fan blade edge cover on the end with two holes. Insert the edge cover into the fan blade at an angle.
3. Flip the fan blade over and secure it with screws.
4. Repeat for all 6 fan blades to complete this step.

4.2. Pasang Bilah Kipas

1. Get the motor. Take out all the screws fixing the fan blades inside the motor.
2. Insert the 3-hole end of the fan blade into the motor.
3. Reinstall the screws you just removed to secure the blade.
4. Install all 6 fan blades to the motor step by step.

4.3. Install LED Light Panel

1. First, remove one of the screws on the motor.
2. Secure the metal plate to the motor. Place the metal plate on the motor, rotate it until the screws slide into the slots, and then tighten the screws.
3. Place the LED light panel on the metal plate and connect the light wires.

4.4. Install the Downrod

1. Turn the motor over and remove the cross pin and clamp pin.
2. Get the length of downrod you need to use, then remove its cross pin and clamp pin.
3. Thread the canopy and splice closure through the downrod.
4. Pass the wire through the middle of the downrod.
5. Finally, secure the downrod to the motor port. Fix the cross pin and clamp pin.

4.5. Fix the Mounting Bracket to the Ceiling

1. Secure the mounting bracket to the ceiling using appropriate screws. Ensure it is firmly attached to a structural support.

4.6. Hang the Downrod and Complete Wire Connections

1. Hang the downrod assembly onto the mounting bracket.
2. Connect the receiver wires: Connect wires of the same color together.
3. Connect the ceiling wires to the receiver wires.
4. After sorting out all the cables, put them into the mounting bracket together with the receiver.

4.7. Cover the Lampnaungan

1. Cover the mounting bracket and receiver with the canopy. Finally, tighten the screws to secure.
2. Tutupi lampshade. This completes the ceiling fan installation.

5. Petunjuk Pengoperasian

Your Ohniyou ceiling fan offers multiple ways to control its functions for optimal comfort.

5.1. Operasi Kontrol Jarak Jauh

The included remote control allows for convenient adjustment of fan speed, light settings, and other features.

Terperinci view of the remote control functions, including light on/off, 3-color switch, color temperature, dimming, reversible motor, and 6-speed fan control.

• Lampu ON/OFF: Toggle the light.
• 3 Color Switch: Cycle through Warm (3000K), Neutral (4500K), and Cold (6000K) light.
• Tombol Peredup: Sesuaikan kecerahan dari 10% hingga 100%.
• 6 Speed Button: Select fan speed from 1 (low) to 6 (high).
• Motor Reversibel: Switch between summer (cooling) and winter (air circulation) modes.
• Pengaturan Timer: Set a 2-hour timer for automatic shut-off.
• Mode Cahaya Malam: Activate a low-intensity light setting.
• Pairing Button (SETUP): Long press for 3 seconds to pair the remote.

5.2. Kontrol Aplikasi Seluler

Control your fan conveniently from your smartphone using the dedicated app.

The mobile application interface for controlling the fan, showing fan speed, light settings, and other options.

Scan the QR code to download the Fan Lamp Pro app or visit http://www.jasonghost.com/fanlamppro/index-en.html. Ensure Bluetooth is enabled on your phone for pairing. Turn the fan light on and off 5 times for app matching.

• Unduh Aplikasi: Scan the QR code provided in the manual or search for "FanLamp Pro" in your app store.
• Hubungkan ke Aplikasi: Ensure your phone's Bluetooth is turned on. Turn the ceiling fan light on and off 5 times to enter pairing mode.
• Fungsi Aplikasi: Control light color temperature and brightness, wind speed, wind direction (reversible), night light mode, and timing through the app.

5.3. Dimmable Lighting

The integrated LED light offers adjustable brightness and color temperature to suit your preference.

The fan light offers three color temperatures (Warm, Neutral, Cool) and smooth dimming from 10% to 100% brightness.

• Suhu Warna: Choose from Warm Light (3000K), Neutral Light (4500K), and Cold Light (6000K).
• Penyesuaian Kecerahan: Smoothly dim the light from 10% to 100%.

5.4. Reversible Function

The reversible DC motor allows for optimal air circulation in both warm and cool seasons.

Illustrates the reversible function for summer cooling (downward airflow) and winter air circulation (upward airflow).

• Modus Musim Panas: Blades rotate counter-clockwise, pushing cool air downwards to create a cooling effect.
• Modus Musim Dingin: Blades rotate clockwise, drawing cool air up and pushing warm air down from the ceiling, helping to circulate heat.

5.5. Speed Control and Quiet Operation

The fan offers 6 adjustable wind speeds and operates with minimal noise.

The fan offers 6 speed settings, from gentle breeze to strong cool wind, with a quiet operation of approximately 30dB.

• Kecepatan 1-2: Comfortable wind, suitable for reading and sleeping.
• Kecepatan 3-4: Natural wind, ideal for enjoying family time.
• Kecepatan 5-6: Cool wind, effective for cooling down quickly during exercise.
• Operasi senyap: The DC motor ensures quiet operation, rated at 30dB, suitable for bedrooms and quiet environments.

6. Pemeliharaan

Perawatan rutin memastikan umur panjang dan kinerja optimal kipas langit-langit Anda.

• Pembersihan: Bersihkan bilah kipas dan rumah motor secara teratur dengan kain lembut dan kering.amp kain. Jangan gunakan pembersih atau pelarut yang bersifat abrasif.
• Inspeksi Pisau: Periksa secara berkala apakah semua sekrup mata pisau sudah kencang. Sekrup yang longgar dapat menyebabkan goyangan dan suara bising.
• Penutup Cahaya: Clean the light cover gently with a soft cloth.
• Motor: Motor DC dirancang untuk pengoperasian jangka panjang tanpa perawatan. Tidak diperlukan pelumasan.
• Pemutusan Daya: Always disconnect power to the fan before cleaning or performing any maintenance.

7. Penyelesaian masalah

If you encounter issues with your Ohniyou ceiling fan, refer to the following common solutions or contact customer support.

7.1. Remote Control Not Working / Pairing Issues

If your remote control is unresponsive or needs re-pairing:

1. Use the wall switch or another method to cut off the power to the fan.
2. Tunggu selama 5 detik.
3. Sambungkan kembali daya.
4. Within three seconds of reconnecting power, long press the "SETUP" (pair) button on the remote. You will hear a "beeping" sound and the light will flash, indicating successful pairing.

7.2. Masalah Koneksi Aplikasi

If you are having trouble connecting the fan to the mobile app:

1. Pastikan Bluetooth di ponsel Anda diaktifkan.
2. Reset the fan: Turn on the wall switch in your room that controls the power of your fan, and then turn it off. Wait about 5 seconds, then turn it on again.
3. Buka "FanL"amp Pro" app.
4. Hit the pair button on the app about 3 times until you hear a beep from the fan and the light flashes.
5. Try to use the app to control the fan.

7.3. Bagian yang Hilang

If your product is missing any parts upon arrival:

• Don't worry, the manufacturer will reissue the parts.
• Please feel free to contact customer support at ohniyou@ledphy.com. They aim to reply within 12 hours.

8. Spesifikasi

Detailed dimensions and technical specifications of the Ohniyou 60-inch ceiling fan.

9. Garansi dan Dukungan

For any product-related inquiries, missing parts, or technical support, please contact Ohniyou customer service.

• E-mail: ohniyou@ledphy.com
• Waktu Respon: Customer support aims to reply within 12 hours.
• Informasi Garansi: Specific warranty details are typically provided with the product packaging or upon registration. Please refer to your purchase documentation for comprehensive warranty terms and conditions.
