BEFAMALI Rechargeable Spotlight Flashlight W5225 User Manual

1. Pendahuluan

This manual provides detailed instructions for the safe and effective use of your BEFAMALI Rechargeable Spotlight Flashlight, Model W5225. Please read this manual thoroughly before operating the device and retain it for future reference.

2. Apa yang ada di dalam kotak

• 1x Rechargeable Spotlight
• Kabel Pengisian USB 1x
• 1x Manual Bahasa Inggris
• 1x Spotlight Lanyard
• 4x Colored Lenses (White/Blue/Red/Yellow)

Figure 2.1: Package contents including the spotlight, charging cable, lanyard, and colored lenses.

3. Fitur Produk

• Kecerahan Tinggi: Upgraded P90 chip, maximum brightness can reach 99,000 lumens, beam distance up to 5,000 feet/1,500 meters.
• Pengisian Cepat: Advanced USB-C charging technology allows full charge in approximately 3 hours.
• Extended Runtime & Power Bank: Built-in 10000mAh rechargeable battery provides 10-30 hours of outdoor lighting. Features a USB output port for charging other devices.
• Beberapa Mode Pencahayaan: 4 Main light modes (High-Mid-Strobe-SOS) and 3 Side light modes (High-Mid-Night warning light).
• Colored Lenses: Includes 4 colored lenses (white/red/yellow/blue) to switch between different light colors.
• Daya tahan: IPX6 waterproof rating and rugged, impact-resistant material for outdoor and indoor use.
• Penggunaan serbaguna: Can be used handheld or with an adjustable stand, also functions as a work light. Ideal for outdoor activities like boating, hiking, fishing, and night work.

Figure 3.1: The spotlight demonstrating its 99,000 lumen brightness and long-range illumination.

Figure 3.2: The spotlight connected to a USB-C power adapter for fast recharging.

Figure 3.3: The spotlight's USB output port being used to charge a mobile device, highlighting its power bank function.

4. Pengaturan

4.1 Pengisian Awal

Before first use, fully charge the spotlight using the provided USB-C charging cable. Connect the USB-C end to the spotlight's input port and the USB-A end to a compatible USB power adapter (not included). The power display indicators will show charging progress.

4.2 Memasang Tali Pengikat

Thread the lanyard through the designated loop on the spotlight's handle for secure carrying.

4.3 Menggunakan Stand Lipat

The integrated foldable stand can be deployed to position the spotlight on a flat surface, allowing for hands-free operation. Adjust the stand to achieve the desired angle.

4.4 Attaching Colored Lenses

To change the light color, twist the front bezel of the main light counter-clockwise to remove it. Place the desired colored lens (red, blue, or yellow) over the main light, then reattach the bezel by twisting clockwise until secure. The white lens is pre-installed.

Figure 4.1: The BEFAMALI W5225 spotlight shown alongside its interchangeable red, blue, and yellow colored lenses.

5. Operasi

5.1 Main Light Modes

Press the main light button (located on the handle) to cycle through the 4 main light modes:

• Tinggi: Maximum brightness for long-range illumination.
• Sedang: Reduced brightness for general use and extended battery life.
• Strobo: Lampu yang berkedip sebagai tanda atau tanda disorientasi.
• SOS: Sinyal kode Morse internasional untuk keadaan darurat.

Figure 5.1: A visual representation of the BEFAMALI W5225 spotlight's four main light modes: High, Medium, Strobe, and SOS.

5.2 Side Light Modes

Press the side light button (located on the top panel) to cycle through the 3 side light modes:

• Tinggi: Bright area illumination for close-range tasks.
• Sedang: Softer area illumination for general use.
• Night Warning Light (Red & Blue): Flashing red and blue lights for emergency signaling or increased visibility.

Figure 5.2: The BEFAMALI W5225 spotlight's three side light modes are shown: High, Medium, and a Red & Blue warning light.

5.3 Fungsi Power Bank

To use the spotlight as a power bank, connect your device's charging cable to the USB output port on the spotlight. The spotlight's internal battery will then charge your connected device.

Figure 5.3: The BEFAMALI W5225 spotlight connected to a smartphone via its USB output port, demonstrating its power bank functionality.

6. Pemeliharaan

6.1 Pembersihan

Usap lampu sorot dengan lembut, damp cloth. Do not use abrasive cleaners or solvents. The IPX6 waterproof rating means it can withstand splashes and rain, but it should not be submerged in water.

6.2 Perawatan Baterai

To prolong battery life, avoid fully discharging the battery frequently. Recharge the spotlight regularly, especially if it has not been used for an extended period. Store in a cool, dry place.

7. Penyelesaian masalah

7.1 Lampu Tidak Menyala

• Pastikan baterai terisi daya. Hubungkan ke sumber daya menggunakan kabel USB-C.
• Check if the correct button (main light or side light) is being pressed.

7.2 Baterai Tidak Mengisi Daya

• Verify the USB-C cable is securely connected to both the spotlight and the power adapter.
• Try a different USB-C cable or power adapter to rule out faulty accessories.
• Pastikan adaptor daya berfungsi dengan benar.

7.3 Output Cahaya Redup

• The battery may be low. Recharge the spotlight fully.
• Ensure the light mode is set to 'High' for maximum brightness.

8. Spesifikasi

9. Garansi dan Dukungan

For warranty information or technical support, please refer to the product packaging or contact the retailer where the product was purchased. Additional protection plans may be available from third-party providers.
